Model series 020 – Yard Machines series 20 User Manual
Page 15
15
Ref.
No.
Part No.
Description
1.
710-0654A
Hex Ind. Washer Screw 3/8-16
x 1.0
2.
782-0048
Cutting Deck: 20”
3.
749-1077
Lower Handle
4.
749-1076
Upper Handle
5.
747-0976A
Control Handle (Bail)
6.
731-0872A
Rear Flap
7.
17098
Hinge Clip
8.
710-1044
Screw 3/8-24 x 1.5” Group 8
9.
936-0524A
Blade Bell Support
10.
753-0588
Blade Adapter Kit
11.
742-0640
Cutting Blade
12.
731-0064
Discharge Chute
13.
710-0932
Carriage Screw 1/4-20 x 1.0”
14.
736-0173
Flat Washer
15.
712-0324
Lock Nut 1/4-20
16.
710-3008
Hex Bolt 5/16-18
17.
712-3004A
Lock Nut 5/16-18
18.
710-1205
Eye Bolt
19.
710-0262
Carriage Bolt 5/16-18 x 1.5”
20.
736-0119
Lock Washer
21.
712-0267
Nut 5/16-18
22.
734-1779
Wheel
23.
738-0533
Shoulder Screw .498 x 1.635
24.
736-0105
Bell Washer
25.
712-0798
Flange Lock Nut
26.
726-0240
Cable Tie
27.
746-0946
Control Cable (48.25” lg.)
746-0957
Control Cable (37.25” lg.)
28.
736-0331
Bell Washer
Model Series 020
