DESCRIPTION OF THE APPLIANCE
4
1 Worktop
2 Programme chart
3 Low Temperature Button
4 Buzzer OFF button
5 Start button
6 Control lights
0
7 Mains-On Light
0
8 Programme Selector Dial
0
9 Rating Plate
10 Door Handle
11 Fluff filter
12 Adjustable feet
13 Side vent outlets
14 Ring nut
15 Rear vent outlet
12
10
11
9
1
7 8
2
C
B
kg 5
A
D
kg 2
6
4
3 5
13
14
15
