Model 589 – Yard-Man 589 User Manual
Page 17
17
Model 589
Ref.
No.
Part No.
Part Description
1.
749-0438D
Upper Handle
2.
647-0004
Control Handle
3.
710-1270
C-Sunk Screw 1/4-20 x 1.3”
4.
746-0883
Throttle Housing
5.
712-0324
Hex Lock Nut 1/4-20
6.
720-0279
Handle Knob
7.
710-1205
Rope Guide
8.
710-1174
Carriage Bolt 5/16-18 x 2”
9.
736-0451
Shoulder Washer .320 ID x .930 OD
10.
720-0284
Wing Nut
12.
746-0554
Blade Control Cable 40.5 “
13.
749-0907B
Lower Handle
14.
664-04012
Grass Bag
15.
747-04080
Grass Catcher Frame
16.
712-0397
Handle Knob
17.
782-5004A
Rear Baffle - RH
18.
714-0104
Hairpin Clip
19.
731-04134
Grass Bag Door
20.
732-0700
Wire Rod
21.
731-1236
Trailshield
22.
732-04090
Door Spring, RH
23.
747-0996
Chute Door Pivot Rod
24.
750-04162
Spacer .390 O.D. x .810 I.D. x .95”
25.
687-02032
Handle Brkt Ass’y, w/Adj - LH
687-02034
Handle Brkt Ass’y, w.Adj. - RH
26.
787-01103
Deck 21”
27.
710-0654A
Hex Washer Screw 3/8-16 x 1.0
28.
710-0703
Hex Carriage Screw 1/4-20
29.
712-3005
Flange Lock Nut 3/8-16
30.
736-0356
Bell Washer .390 ID x .380 OD
31.
732-04089
Door Spring, LH
32.
687-02033
Handle Bracket Assembly - RH
682-02031
Handle Bracket Assembly - LH
33.
710-0286
Machine Screw 1/4-20 x .500
34.
710-0896
Hex Washer Screw 1/4-14 x .625
35.
710-0216
Hex Cap Screw 3/8-16 x .75
36.
720-0312
Foam Grip
37.
17488A
Pivot Bar - RH
17489A
Pivot Bar - LH
38.
736-0105
Spring Washer .375 ID x .870 OD
39.
732-0866
Spring Lever
40.
738-0507B
Shoulder Screw
41.
734-2043
Rear Wheel Assembly 14 x 2.1
42.
736-0272
Flat Washer .510 ID x 1.00 OD
43.
736-0182
Wave Washer .500 ID x 1.0 OD
44.
738-0481A
Shoulder Screw
45.
14578
Front Height Adjuster - RH
14579
Front Height Adjuster - LH
46.
734-2004A
Front Wheel Assembly 8 x 2.1
47.
738-0102
Shoulder Bolt
49.
712-0431
Flange Lock Nut 3/8-16
50.
782-5002A
Front Baffle
51.
782-5003
Rear Baffle - LH
52.
710-1017
Tap Screw 1/4-14 x .625.
53.
15261A
Height Adjustment Plate
54.
720-0426
Height Adjustment Knob
55.
15262B
Pivot Bar
56.
732-0404
Spring Lever
57.
748-0376C
Blade Adapter
58.
742-0741
21” Mulching
59.
736-0524A
Blade Bell Support
60.
710-1044
Hex Cap Screw 3/8-24 x 1.5
61.
731-1506
Front End Cover
62.
731-1426
Hub Cap
Ref.
No.
Part No.
Part Description
