LRTZ2600
1
T3002-12101
PIPE COMP.
1
2
3520-12213
SHAFT
1
3
T3076-11330
GRIP ASSY
1
4
6420-17300
HANGER ASSY
1
5
6420-17400
• HANGER COMP.
1
6
9366-17110
• • HANGER
1
7
9366-17120
• • CLAMP
1
8
6420-17410
• • SLEEVE
1
9
0263-90525
• SCREW
1
10
848A2N90R0
NAME-PLATE
1
11
3436-91170
CAUTION-PLATE
1
12
6489-14000
HANDLE ASSY
1
14
6420-14320
• CLAMP
1
15
0263-90535
• SCREW
4
16
T3300-17100
STRAP ASSY
1
17
T3002-91000
TOOL-SET
1
18
1030-91340
• DRIVER
1
19
T3002-91310
• SOCKET
1
20
09007-00425
• WRENCH
1
Key#
PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
21
3540-91120
• SPANNER
1
22
3540-91110
• BAR
1
Key#
PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.1 DRIVE UNIT
1
6598-13110
LEVER, clamp
1
2
0290-20615
WASHER 1
M6
3
6782-13650
WASHER 1
6x16x2.0
4
6782-13141
ANGLE ADJUSTER
1
5
0225-10612
BOLT 2
M6x12
6
6782-13200
CASING A SET
1
7
–––––––––
• CASING A
1
8
6782-13220
• PLATE
1
9
3199-13350
GREESE FITTING
3
10
6782-13250
LABEL
1
11
0263-10408
SCREW 2
M4x8
12
6598-13320
COVER
1
13
6598-13330
SNAP RING
1
14
6782-13340
BEBEL GEAR
1
15
04065-02612
SNAP RING
1
16
06004-06000
BEARING
1
17
6782-13370
CRANK SHAFT
1
18
04064-02815
SNAP RING
1
19
6782-13411
BLADE
2
20
6782-13430
BEARING 1
608Z
23
6782-13460
FELT
1
24
3884-11750-10
SCREW
1
25
3880-11780
WASHER
6
26
6598-13510
SCREW 3
L17
27
6598-13530
SCREW 2
M5x20
28
6782-13540
GUIDE PLATE
1
29
6782-13550
PLATE
1
30
6782-14470
NUT 2
M5
31
3880-11790
NUT 4
M6
32
6782-13650
WASHER 1
6x15x2.0
33
6598-13430
BEARING 1
608
2RS
34
04065-02212
SNAP RING
1
35
T4008-06010
SHAFT KIT
1
44
0280-10605
• NUT
1
M6
45
0290-20615
WASHER
1
Key#
PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
46
6598-13620
O-RING 1
P41
47
04065-02612
SNAP RING
1
48
06004-06000
BEARING
1
49
6780-13710
CASING B
1
50
6782-13650
WASHER
1
51
0225-10612
BOLT 1
M6x12
52
6782-13720
WASHER 1
5x10x1.0
53
01252-30510
BOLT 1
M5x10
54
3350-21320
BOLT 1
M5x30
55
6782-13810
JOINT
1
56
6598-13820
GEAR SHAFT B
1
57
6782-13830
BEARING 2
6900RS
58
04065-02212
SNAP RING
1
59
6782-13850
BEVEL GEAR
1
60
6598-13330
SNAP RING
1
61
6598-13860
PACKING
1
62
6598-13871
PLATE
1
63
0263-10410
SCREW 2
M4x10
64
6782-13910
BLADE COVER
1
65
6782-06010
COVER SET
1
66
6782-13441
• COVER
1
67
6782-13470
• GASKET
1
68
6783-13450
• BOLT
4
M4x12
Key#
PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.2 CUTTING UNIT
