A
SSEMBLING
Y
OUR
B
LENDER
Before assembling your blender wash all loose parts, except for motor base in warm
soapy water, rinse thoroughly and dry. All parts except for motor base can be
washed in the top rack of dishwasher. Motor base can be wiped clean with a damp
cloth.
1. Place gasket onto blade assembly by slipping it over the four blades and
letting it rest on blade assembly flange.
2. Place blade assembly into blade assembly holder.
3. Thread blade assembly holder onto bottom of mixing jar by turning clockwise.
4. Put lid onto mixing jar by pressing into place making sure that it is properly
lined up to cover pour spout.
5. Drop lid cap into lid by lining up flanges over flange openings and then turn a ¼
turn clockwise to lock in place.
6. Entire mixing jar assembly can now be placed on motor base by setting it
down in various positions.
Lid Cap
Lid
Mixing Jar
Gasket
Blade Assembly
Blade Assembly Holder
Motor Base
