Part identification chart – Weider WEBE19510 User Manual
Page 5
5
M10 x 80mm Bolt (22)
M10 x 20mm Bolt (21)
M10 x 65mm Bolt (19)
M10 x 45mm Bolt (18)
M8 x 70mm Bolt (25)
M10 Nylon Locknut (20)
M8 Nylon Locknut (28)
M10 Washer (15)
Refer to the drawings below to identify small parts used in assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST on page 18 of this manual.
Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
PART IDENTIFICATION CHART
