5 MaxxBass User Guide
MaxxBass includes stereo analog inputs and outputs designed for easy connection to most audio systems. The MaxxBass 101
supports stereo input and output with terminal block, XLR and TRS connections (+4dBu sensitivity), as shown in Figure 4.
The MaxxBass 102 supports unbalanced RCA connector at -10dBu sensitivity as shown in Figure 5.
Both MaxxBass 101 and MaxxBass 102 support an RS232 serial connector on their rear panel for future updates.
External Power Supply
Both MaxxBass systems are provided with an external 16V AC power supply. Different power supplies are provided to custom-
ers in different regions of the world as shown in Table 1.
Table 1. MaxxBass Included Power Supply
Geographic Region Input Voltage Output Voltage
Americas 110V AC 16V AC
Europe 220V AC 16V AC
Japan 100V AC 16V AC
