This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
each part refers to the key number of the part.
Important: Some parts may have been pre-assembled for
shipping purposes. If you cannot find a part in the parts bags, check to see if it has been pre-assembled.
M10 x 81mm Bolt (35)
Spacer (37)
M6 x 16mm Screw (15)
M10 x 65mm Bolt (18)
M8 Nylon Locknut (13)
M8 Washer (38)
M10 Nylon Locknut (19)
M6 Washer (25)
M10 Washer (24)
M10 x 72mm Bolt (40)
M10 x 178mm Bolt (17)
M8 x 58mm Bolt (39)
M6 x 38mm Screw (16)
M4 x 16mm Screw (34)
M10 x 68mm Bolt (44)
