Page 2
OVEN PARTS
2
For Models: GBS307PRB00, GBS307PRQ00 GBS307PRS00
(Black) (Designer White) (S.Steel)
8186301
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1
Literature Parts
8303647 Installation
Instructions
8303645 Use & Care Guide
8301758 Tech Sheet
4449237 Cookbook Conv.
8302333 Installation/
Undercounter
9759133 Safer Cooking Tips
8301928 Installation
Instructions,
M/W Trim Kit
2
Trim, Side
(Right Hand)
8302908 Black
8303213 S.Steel
8302909 White
(Left Hand)
8302907 Black
8303214 S.Steel
8302910 White
3400832 Screw
6
4452490 Spacer, Foam
7
4455865 Top, Chassis
4449809 Screw
8
4448520 Bumper, Door
9
4452158 Tube, Vent
3196176 Screw
10
4452165 Lens, Light
11
4452368 Oven Light Assy
12
4452166 Bulb, Light
13
Hinge Receiver
4455605 Left Hand
4455606 Right Hand
14
9759060 Frame, Front
4449040 Screw
4450118 Nut
15
4455382 Gasket, Door
16
4452337 Insulation,
Bottom Vent
19
4451478 Support, Insulation
4449809 Screw
20
4451605 Cap, Spacer
21
Rail, Side
8303115 Right Side
8303116 Left Side
4448444 Grommet
4449154 Screw
24
9759525 Latch, Motorized
4449154 Screw
25
4455641 Side, Chassis
(R.H. & L.H.)
4449809 Screw
26
4452234 Back, Chassis
4449809 Screw
27
Liner, Oven
(Not serviceable)
29
4455636 Sensor
4449154 Screw
33
4452496 Deflector (Btm)
4449809 Screw
37
9759243 Thermostat (TOD)
(Temp.) SPST
43
9759713 Base, Chassis
4449809 Screw(2)
49
4448933 Retainer, Gasket
4449154 Screw
50
4451747 Cover, Back
4449809 Screw
53
4449845 Support, Bracket
4449809 Screw
55
Trim, Bottom
8303583 Black Model
8303584 White Model
8303582 S.Steel
4452152 Bracket, Bottom
Mounting
3400832 Screw
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449316 Insulation, Wrap
4450365 Insulation, Back
