Burner dimensions – Weil-McLain CG50 User Manual
Page 4
Weil-McLain 88 Water and Steam Boilers — Series 2 —
For Gas, Light Oil, & Gas/Light Oil-Fired Burners
4
Part No. 550-142-027/0508
Burner dimensions
Beckett model CG10
Figure 2
Beckett models CG25 and CG50
Figure 3
Burner
Model
Number
Dimensions, In Inches
A
B
C
D
E
F
G
H
I
J
K
L
Pipe
Thread
Overall
Width
Square
Flange
Width &
Height
Bolt
Circle
Maximum
Tube O.D.
Centerline
To End Of
Manifold
Tube
Centerline
To Manifold
Centerline
Overall
Length
(Max.)
Burner
Length
Centerline
To Top Of
Burner
Centerline
To Bottom
Of Burner
Centerline
Of Manifold
To End Of
Tube
Insertion
Depth
(Max.)
CG10
11.70
10.0
10.25
4.9
8.1
6.0
26.0
22.0
6.8
8.2
11.0
4.0
1-1/4 NPT
CG25
20.90
12.00
10.25
6.9
9.3
6.8
33.2
29.2
4.1
12.8
17.8
4.0
2 NPT
CG50
24.4
12.00
10.25
7.7
10.5
7.5
33.6
29.6
4.1
14.6
17.4
4.0
2-1/2 NPT
