M10 Nylon Locknut (76)
M8 Nylon Locknut (65)
M6 Nylon Locknut (69)
M8 Flange Nut (19)
M8 Washer (59)
M10 Lock Washer (68)
M6 x 13mm Bolt (92)
M4 x 16mm Screw (62)
M4 x 19mm Screw (77)
M4 x 12mm Flat
Head Screw (85)
M10 x 25mm Button
Head Screw (87)
M8 x 19mm Button
Head Screw (86)
M10 Nut (47)
M4 x 5mm Screw (104)
M10 x 53mm Carriage Bolt (61)
M10 x 42mm Button Head Bolt (71)
M10 x 50mm Bolt (63)
1/4” x 45mm Screw (58)
1/4” x 16mm Screw (82)
M10 Washer (75)
PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST on the reverse side of this page.
Note: Some small
parts may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
