Worth Data RF Laser User Manual
Rf laser, Quickstart and installation guide, Rf laser reader installation - pc serial port

Wireless RF Laser Bar Code Reader
QuickStart and Installation Guide
RF Laser
have to insert the original Windows® CD. The Mac always finds the driver.
In either case, the driver used is the standard keyboard driver. No special
drivers are required.
If you mistakenly abort your driver installation, see the Trouble Shooting
Section of Users Guide in PDF format on the enclosed CD.
RF Laser Reader Installation - PC Serial Port
The Base Station
can be directly
attached to a spare
serial port as shown
here using either the
F36 9 pin cable, or
the F34 25 pin
cable. This configu-
ration requires the
Worth Data F10 5v power supply for powering the Base Station. Upon
power-up, the Base Station LED will flash with 3 more flashes than the
channel setting; i.e. if it is set on Channel 0, it will flash green three times.
If the Channel were set to 7, it would flash green 10 times. See the Users
Guide available in PDF format on the enclosed CD.
RF Laser Reader Installation - Host & Terminal
If you are installing your RF Laser Reader between a dumb terminal and
host computer, please see the Users Guide available in PDF format on the
enclosed CD for installation instructions and details.
For complete setup information, please see the RF Laser Users Guide
available in PDF format on the enclosed CD.
Serial Cable
Full Users Manual available on the Utilities CD in
PDF format. You can also download the Manual and
Setup Menus at http://www.barcodehq.com
