4
220720 A IMAGE 6
INTERCOM COMPONENTS
1. CHANNEL BUTTONS 1-4
Allows you to select between channels. Click one button down to
select a channel. Click the button up to deselect the channel.
2. CHANNEL INDICATORS 1-4
Indicates the selected channel.
3. TALK INDICATOR
Lights when the intercom is activated.
4. SPEAKER
Clearly transmits pure, static-free, two-way voice communication.
5. POWER INDICATOR
Lights when power is on.
6. POWER/VOLUME KNOB
Turns the unit on and off, also controls the volume.
7. MICROPHONE
High-gain microphone monitors your voice.
8. TALK BUTTON
Press to talk. Release to listen.
9. CALL BUTTON
Pages other units on the selected channel.
10. AUTO TALK BUTTON
Locks down for automatic voice-activated monitoring.
1
3 4
5
6
7
8
9
10
2
