Setup Instructions
PokerLite Kit
Style: 7054
Description
With a 360-degree light spread, the Pokerlite is the perfect lighting accessory for an interview or table
setting. The Pokerlite
™ is 17” tall by 21.5” wide and is composed of a white diffusion material with a
removable black duvetyn skirt. There are three densities of bottom diffusion available: Full Stop, ¾ and ½
Stop. The skirt and bottom diffusions attach to the Pokerlite
™ with hook and loop tape.
Product Contains
[1]
Spiderlite
[1] Tilter Bracket
[1] 1000-watt Tungsten Halogen Lamp
[1]
PokerLite
[4] Metal Rods
[1] Full Stop Diffusion Panel
[1] 3/4 Stop Diffusion Panel
[1] 1/2 Stop Diffusion Panel
[2] Black Skirts (cover ½ side each)
[1] Carry Bag
Instructions
Remove the Pokerlite and rods from the carry case. On the black base, there are four Velcro tabs. Find the holes
at the end of these pointing towards the center opening.
Insert the rods into the openings under the Velcro making sure they’re completely in. You can tell if you have
them in far enough if all rods pointing out are of the same length.
First insert one rod into the hole directly beside the hole with a slot opening on the Spiderlite. (Or insert it into a
hole of an adapter ring for the specific light you are using) Second, insert the rod directly opposite the first one.
Finish so that the last rod you insert is into the hole with the slot (if using with the Spiderlite.) The rods are
constructed of sprung stainless steel so they’re made to bend for the purpose of our lighting accessories.
Attach one of the Full Stop, ¾ or ½ Stop densities of diffusion to the bottom of the Pokerlite per your
needs/preference matching up the Velcro along the white edge on the larger opening of the Pokerlite.
Again, per your needs/preference, you can attach the black duvetyn skirt using the Velcro on the outside edge of
the black surface. You can also use the Velcro to hold back portions of the black duvetyn skirt if you want partial
coverage; more light exposure. To fold the skirt up for ½ the vertical coverage, connect the Velcro tabs at the
bottom with the same strip the top is connected to.
* VELCRO is a registered trademark for fasteners of the Velcro
Companies.
