Part identification chart – Weslo 78e 831.29522.0 User Manual
Page 17
Remove this chart and use it to identify small parts during assembly. Save
this chart and the EXPLODED DRAWING/PART LIST for future reference.
PART IDENTIFICATION CHART
3/4 Screw (2) 12
3/4 Tek Screw (3) 2
Handrail Bolt (55) 2
Base Leg Screw (62) 4
Base Leg Screw (62)–4
Handrail Bolt (55)–2
3/4” Screw (2)–12
3/4” Tek Screw (3)–2
