White Rodgers 1F90W-51 User Manual
Page 7
7
Other than
and
, the buttons are
located behind the thermostat door. To open the
door, pull the door out from the top, then swing
it down on its hinges.
On the following pages there are brief descrip-
tions of the display and the thermostat buttons.
BACK OF THERMOSTAT BODY
3-pin Connector
6-pin Connector
Batteries
W14
S3
