FEATURES & OPERATING CONTROLS
2
A. THERMOSTAT
1. Soup Cooker and Cook ’N Hold Warmers are thermostatically
controlled. Power is applied to the heating element according
to the control knob position and the actual temperature at the
sensing element.
2. The desired temperature is controlled by rotating the
TEMPERATURE CONTROL KNOB. The knob may have a
printed “arrow” which points to specific functions (e.g. COOK,
HOLD), or to a graphic scale where “wider” corresponds to
higher temperature.
3. The dial will rotate approximately 300°, and will reach a stop
at both ends. The OFF position is marked.
B. ADJUSTABLE
LEGS
1. Countertop warmers may be equipped with adjustable legs.
These legs allow for:
a. leveling the warmer
b. ventilation around the warmer, and
c. cleaning under the warmer.
2. Adjustable legs are available as options. However, if adjustable
legs are supplied with the warmer, the legs MUST be properly
installed before the warmer is placed into operation.
MOUNT INTO
THREADED
HOLES IN
WARMER
FRAME
TURN BOTTOM
PORTION TO
ADJUST
LO
W
MEDIU
M
H
IG
H
OFF
PREHEAT
KNOB FOR LLSC-7,
LLSC-11 AND 6411 SOUP
COOKERS
KNOB FOR LLCH-1220
COOK ‘N HOLD WARMERS
