© 2001-2005 Wilbur Curtis Company, Inc. Printed in U.S.A. DEC/05 – 7751 — F3120 rev.B
GEM-5 — Heated
Satellite Stand (Tall)
*Includes TWO Gem-3 Satellite Servers. **Optional 208/240; 3 phase. Specify 3 Wire Plus Ground or 4 Wire Plus Ground.
Remote Service/Optional Accessories
Additional Satellite Servers and optional warming stands allow you to
easily expand coffee service while maintaining temperature and great
tasting flavor.
• GEM-3 Insulated Satellite Serv er — locking lids guard against acci-
dental spills.
• GEM-5 Heated Stand — raises Satellite to 9”. Ideal height for filling
decanters.
• GEM-8 Heated Stand — raises Satellite to 5.375”. Ideal height for
cup service.
GEM-12D
9"
1.5"
4"
(10.2 cm)
12.5"
9"
7"
5.63"
20"
18.19"
5.75"
14.5"
16.75"
1"
3.75"
16.5" 18"
(45.7 cm)
25"
(63.5 cm)
(41.9 cm)
(41.9 cm)
(2.5 cm)
(41.4 cm)
(31.8 cm)
(22.9 cm)
(36.8 cm)
(14.7 cm)
(46.2 cm)
(50.8 cm)
(17.8 cm) (14.2 cm)
(22.9 cm)
(3.8 cm)
THIS DIMENSION CAN
INCREASE 1" BY ADJUSTING LEGS
CURTIS CURTIS
®
Factory Settings
GEM-12D
Brew Temperature: 200 °F
Water Bypass: ON
Brew Volume:
36 Cups (192 oz.)
GEM-3 —
Insulated
Satellite Server
WILBUR CURTIS COMPANY, INC.
6913 Acco Street, Montebello, CA 90640-5403
Telephone: 800-421-6150 · 323-837-2300
Fax: 323-837-2406
www.wilburcurtis.com
SPECIFICATIONS
GEM-12D*
Brewing Heads 2
Finished Brew Capacity 36 Cups/Head (72 Total)
Dimensions (H x W x D) 29” x 18” x 16.5”
Electrical** 220VAC/1 Phase/3 Wire Plus Ground
Power Requirements 6300W/29A
Water Inlet .375” Compression
Shipping Weight (lbs.) 90 lbs.
Cube (cu. ft.) 8.6 cu. ft.
Optional Accessories GEM-3 Satellite GEM-5 Stand GEM-8 Stand
Capacity 1.5 Gallon (36 cups) N/A N/A
Dimensions (H x W x D) 9” x 9” x 11” 9” x 9” x 9” 5.375” x 9” x 9”
Voltage N/A 110VAC/60Hz 110VAC/60Hz
Power Requirements N/A 100W/1A 100W/1A
Shipping Weight (lbs.) 12 lbs. 7 lbs. 6 lbs.
GEM-8 — Heated
Satellite Stand (Std.)
