WiLBUR CURTiS COmPANy, iNC.
6913 Acco Street, Montebello, CA 90640-5403
Telephone: 800-421-6150 · 323-837-2300
Fax: 323-837-2406
www.wilburcurtis.com
© 2008 Wilbur Curtis Company, Inc. Printed In U.S.A · FEB/08 – 8444 – F-3205 revC
TLP 18”
SPECiFiCATiONS TLP 18” TLP 24”
Brewing Heads
Dimensions (H x W x D)
Clearance for Airpot
Electrical
Power Requirements
Cord & Plug
Water Source*
Shipping Wight (lbs.)
Cube (cu. ft.)
Finished Brew Capacity-Full Brew
Finished Brew Capacity-Half Brew
1
17.875” x 9” x 16.5”
11.875”
120VAC/60Hz
1500W/12.5A
6 ft./NEMA 5-15P
.75” Flare
31 lbs.
3.478
2.5L (84.5 oz.)
1.25L (42.25 oz.)
1
24” x 9” x 16.5”
18”
120VAC/60Hz
1500W/12.5A
6 ft./NEMA 5-15P
.75” Flare
35 lbs.
5.73
2.5L (84.5 oz.)
1.25L (42.25 oz.)
SPECiFiCATiONS TLXA25
Finished Brew Capacity
Master Pack
Clearance for Airpot
Shipping Wight (lbs.)
Cube (cu. ft.)
2.5L
6
11”
32 lbs.
3.79
CAP-T1*
2.5L
1
16.5”
5 lbs.
.73
CAP-T1PS
N/A
1
2 lbs.
.25
CAP-T25
2.5L
1
11.5”
4 lbs.
.51
Plastic Stand
for CAPT25
TLP 24”
Set-Up is Easy!
Set-up on the new TLP Low Profile Brewing Systems is easy. Simply plumb in water supply, plug in
the system’s built-in cord, and turn the machine on. The Curtis ADS System will sense a dry probe and begin filling the tank
automatically. Once the water in the tank has reached the proper level, the element will automatically turn on and begin
heating. In minutes, the correct brewing temperature will be reached, and you’ll be ready to brew!
7.5”
(18.8 cm)
1.25”
(3.2 cm)
24”
(61.0 cm)
18.875”
(47.9 cm)
18”
(45.7 cm)
16.5”
(41.9 cm)
9”
(22.9 cm)
15.5”
(34.4 cm)
13”
(33.0 cm)
6”
(15.2 cm)
9”
(22.9 cm)
17.875”
(45.4 cm)
12.75”
(32.4 cm)
11.875”
(30.2 cm)
9”
(22.9 cm)
6”
(15.2 cm)
2”
(5.1 cm)
7.5”
(18.8 cm)
1.25”
(3.2 cm)
16.5”
(41.9 cm)
9”
(22.9 cm)
15.5”
(34.4 cm)
* Water Filtration Device Reccommended
* For TLP 24” Only
