Part identification chart – Weider WEBE06110 User Manual
Page 5
5
M10 x 130mm Bolt (9)
M8 Washer (17)
M10 Washer (29)
M10 Nylon Locknut (30)
M10 x 70mm Bolt (26)
M8 x 40mm Bolt (27)
M8 x 55mm Bolt (25)
M8 Nylon Locknut (13)
M8 x 50mm Bolt (19)
This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
each part refers to the key number of the part from the PART LIST on page 14.
Important: Some parts may
have been pre-assembled for shipping purposes. If you cannot find a part in the parts bags, check to
see if it has been pre-assembled.
PART IDENTIFICATION CHART
