6 030-300108D
4. Product Specifications
D IMENSIONS
Height – 7.5 in (19 cm)
Width – 7.78 in (19.76 cm)
Depth – 1.9 in (4.82 cm)
W EIGHT
Approx. 2.30 lbs (1.04 kg) with power supply
E NVIRONMENTAL
Ambient Operating Temperature – +32 to +113°F (0 to +45°C)
Relative Humidity – 5 to 95%, non-condensing
P OWER S UPPLY
120 VAC (
±
10%) wall-mount power supply
P OWER C ONSUMPTION
Less than 10 watts typical from 120 VAC
C ONNECTORS
POWER – 3-pin mini-DIN connector
LINE (DSL) – 6-pin (RJ-11) modular jack
ETHERNET – 8-pin (RJ-45) modular jack
E THERNET C ONNECTOR P INOUT
An RJ-45 type that carries the Receive data on Pins 1 and 2, and the Transmit data on Pins 3 and 6
E THERNET I NTERFACE
Provides transmit and receive data paths for 10Base-T Network Connection.
LINE (DSL) C ONNECTOR P INOUT
An RJ-11 type that carries combined ADSL and POTS signals on Pins 3 and 4.
DSL
DSL Line Code – Discrete MultiTone (DMT) (Alcatel)
DSL Rates – 32 Kbps to 8 Mbps downstream and 32 Kbps to 800 Kbps upstream
Power Spectral Density – -40 dBm/Hz
DSL Impedance – 100 Ohms
DSL Performance – per Category 1 in ANSI T1.413
EMC
FCC, Class B
EN50081-1, Class B
EN50082-1
GR-1089-CORE, Issue 2
S AFETY
UL 1950
cUL
EN60950
R EGULATORY A PPROVAL
UL
CSA
