A-8
Exploded View List
1. Hinge Pin
2. Left Endcap
3. Shroud
4. Handle
5. Warming Rack
6. Cooking Grates
7. Flavorizer ® Bars
8. Cooking Box
9. 1/4-20 keps nut
10. Slide Out Bottom Tray
11. Work Surface
12. Catch Pan Holder
13. Left Trim Rear Assembly Arm
14. 1/4 - 14 x 5/8 inch bolt
15. Left Trim Piece
16. Left Trim Front Assembly Arm
17. 1/4 - 20 x 2 1/4 inch bolt
18. Swing-up Table Asembly
19. 1/4 - 20 x 1 inch bolt
20. Nylon Washer
21. Caster Frame
22. Caster
23. Bottom Rack
24. Wheel
25. Hubcap
26. Hair Pin Cotter
27. Right Endcap
28. Thermometer
29. Handle Hardware
30. Control Panel Knobs
31. Control Panel
32. Control Panel Hardware
33. Crossover ® Ignition Button
34. Crossover ® tube
35. Front / Rear Burner
36. Manifold Hardware
37. Manifold, Hose and regulator (assembled)
38. Catch Pan
39. Disposable Drip Pan
40. Wing Nut
41. Igniter
42. Top Frame Assembly
43. Fuel Gauge
44. Wrap-Around Trim Piece
32. Control Panel Hardware
45. Right Trim Piece
46. Glides
47. Wheel Frame
48. LP Tank
49. 1/4 - 20 x 1 3/4 inch bolt
