weber 5000 User Manual
Genesis, 5000 series, Natural gas barbecue

Serial Number
Please use this number in registering your warranty
and any correspondence with the factory.
GENESIS
®
5000 Series
Natural Gas Barbecue
Owner’s Manual
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
NOTICE TO INSTALLER: These
instructions must be left with the owner
and the owner should keep them for
future use.
WARNING: Follow all leak check
procedures carefully in this manual prior
to barbecue operation. Do this even if
barbecue was dealer assembled.
WARNING: Do not try to light this
appliance without reading "Lighting"
instructions section of this manual.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call
your gas supplier or your fire
department.
86020 6/96
®
Document Outline
- GENESIS ® 5000 Series
- DANGER
- WARNINGS
- WARRANTY
- PATENTS AND TRADEMARKS
- Contents
- General Instructions
- For Installation in Canada
- Storage
- Operating area
- Gas supply testing
- Assembly
- Tools needed
- Supplies needed
- Check package contents
- Assemble wheels
- Assemble frame
- Continue frame assembly
- Complete frame assembly
- Insert casters
- Check the frame assembly
- Install left end panel
- Install the three back panels
- Install side burner locks
- Add cooking box
- Install gas supply
- General Specifications for Piping
- Gas line piping
- Test connections
- Check that all burner valves are off
- Connect flexible hose to manifold
- Install side burner
- Install manifold bracket
- Install brace panel
- Install right end panel
- Install bottom accessory trays
- Install igniter
- Install left hand swing table
- Install right hand swing table
- Check for gas leaks
- Insert Flavorizer Bars and Steam-N-Chips Smoker
- Install cooking grates
- Install the bottom tray
- Install the lid
- Install tool holders, control panel, burner control knobs and FlameCheck button
- Secure the side burner
- Install glass doors
- Complete accessory installation
- OPERATING INSTRUCTIONS
- Lighting
- Crossover Ignition System
- To Extinguish
- Manual Lighting
- To Extinguish
- Lighting the side burner
- Cooking
- Storage and/or Nonuse
- Periodic Cleaning
- Using the Steam-N-Chips Smoker
- To use the Steam-N-Chips Smoker
- Cleaning the Steam-N-Chips Smoker
- Annual Maintenance
- Inspection and Cleaning of the Weber Spider Stopper Guards
- General Maintenance
- Weber Spider Stopper Guards
- Main Burner Flame Pattern
- Main Burner Cleaning Procedure
- Replacing Main Burners
- Crossover Ignition System Operations
- FlameCheck Safety System
- TROUBLESHOOTING
- Side Burner Troubleshooting
- Side Burner Maintenance
- Exploded View
- Parts List
