2
ROT
AR
Y
LA
WN MOWER - - MODEL
NUMBER
961140014
(MFG. ID. NUMBER 961
14001400)
1
2
4
5
6
7
8
9
10
11
12
13
14
14
15
16
56
18
19
20
21
22
23
24
24
24
24
25
26
27
28
28
28
28
29
29
29
29
30
31
31
31
31
32
32
32
32
33
34
35
33
33
33
34
34
34
35
35
35
36
36
36
36
37
37
37
37
38
39
40
41
41
42
43
43
43
44
3
ROT
AR
Y
LA
WN MOWER - - MODEL
NUMBER
961140014
(MFG. ID. NUMBER 961
14001400)
1
194176X428
Control Bar
2
194788
Rope Guide
3
851201X004
Engine W
asher
4
194180X479
Upper Handle
5
151590X479
Lower Handle
6
132004
Nut, Hex
7
191574
Handle Bolt 5/16-18 x 1-3/4
8
86899X004
Up-Stop Bracket
9
189241
Hex W
asher Head Screw #10-24 x 1/2
10
162778
Engine Zone Control Cable
1
1
750634
Screw
12
66426
W
ire Tie
13
51793
Hairpin Cotter
14
189713X428
Knob, Handle
15
412277X428
Discharge Guard
16
850263
Helical Lock W
asher 3/8
17
73800400
Locknut, Hex 1/4-20
18
851074
Hardened W
asher
19
41
1832
T
o
rsion Spring
20
145106
Blade, 20"
21
88602
Hinge Defl
ector
22
150215
Hinge Rod
23
189240
Rear Defl
ector
24
407494X005
Wheel
Adjusting Bracket
25
850977
Blade
Adapter
KEY
P
A
RT
NO.
NO.
DESCRIPTION
26
170345X479
Handle Bracket
Assembly
, RH
27
170346X479
Handle Bracket
Assembly
, LH
28
61537
W
a
sher
, Flat
29
401629
Spacer
30
- - -
Engine, Briggs & Stratton, Model Number 9S502- 1019-B1 (For engine service and replacement parts, call Briggs & Stratton at 1-800-233-3723)
31
401621X004
Selector Spring
32
87877
Selector Knob
33
401
179X004
Axle
Arm
Assembly
34
401630
W
a
sher
, Curved, Cylindrical
35
401638
Shoulder Bolt
36
189168
Wheel and Tire
Assembly
37
409148
Nut, Hex
38
150406
Hex Head Thread Rolling Screw 3/8-16 x 1-1/8
39
414790
Lawn Mower Housing
40
851084
Hex Head Screw 3/8-24 x 1-3/8 Grade 8
41
149741
Thread Cutting Screw 5/16-18 x 3/4
42
404763
Danger Decal
43
73930500
Locknut, Hex 3/8-16
55
700839X479
Baffl
e,
Front
58
128415
Pop Rivet
- -
404764
W
a
rning Decal (not shown)
- -
193732
Operator’s Manual, English
- -
193735
Operator's Manual, Spanish
- -
424070
Repair Parts Manual, English
KEY
P
A
RT
NO.
NO.
DESCRIPTION
NOTE:
All component dimensions given in U.S. inches. 1 inch = 25.4 mm.
IMPORT
ANT
: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your lawn mo
wer and void your warranty
.
