OVEN PARTS
2
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
For Models:GMC275PRB01, GMC275PRQ01, GMC275PRT01, GMC275PRS01
(Black) (White) (Biscuit) (S.Steel)
8186418
1 Literature Parts
Installation
Instructions
8303655 English
8303780 French
Use & Care Guide
(Oven)
8304077 English
8304081 French
Use & Care Guide
(Microwave)
8304078 English
8304082 French
8304173 Tech Sheet
3191638 Safer Cooking Tips
9759133 Safer Cooking Tips
2 Trim, Side
8302927 RH Black
8302929 RH White
8302931 RH Biscuit
8303217 RH S.Steel
8302928 LH Black
8302930 LH White
8302932 LH Biscuit
8303218 LH S.Steel
3 8281236 Screw
4 4448520 Bumper, Door
5 4449809 Screw
6 4452490 Spacer, Foam
7 4455864 Top Chassis
8 Hinge Receiver
4455605 Left Hand
4455606 Right Hand
9 4452158 Tube, Vent
10 4452165 Lens,Light
11 4452368 Oven Light Assy
12 4452166 Bulb,Light
13 8300791 Bracket, Combo
14 4455611 Frame, Front
15 4455381 Gasket, Door
16 3196176 Screw
17 4449040 Screw
18 4452152 Bracket, Mounting
19 4451477 Support, Insulation
21 Rail, Side
8303117 Right Side
8303118 Left Side
22 4449154 Screw
23 4450038 Screw
25 4455641 Side, Chassis
(R.H. & L.H.)
26 4452233 Back, Chassis
27 Liner, Oven
(Not serviceable)
29 4455636 Sensor
30 4449845 Bracket, Support
32 8300154 Insulation,
Bottom Vent
33 9760676 Deflector, Vent
34 4451666 Vent, Center
37 9759243 Thermostat (TOD)
(Temp.) SPST
43 4455529 Base, Chassis
49 4448933 Retainer, Gasket
50 4451747 Cover, Back
51 Trim, Bottom
8302937 Black Model
8302938 White Model
8302939 Biscuit Model
8302940 S.Steel
52 8303503 Vent, Control
53 4451755 Chassis, Back
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449315 Insulation, Wrap
4450364 Insulation, Back
