Literature, Cooktop parts – Whirlpool RS696PXGQ8 User Manual
Page 2
COOKTOP PARTS
2
For Models:RS696PXGB8, RS696PXGQ8
(Black) (Designer White)
8185842
Illus. Part
No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1
Literature Parts
LIT8300770 Installation
Instructions
LIT8300666 Use & Care Guide
LIT3192844 Tech Sheet
LIT3191638 Safe Cooking Tips
2
Cooktop, Glass
3191843 Black
3191189 White
3
3191310 Bracket, Switch
Mounting
4
Element, Surface
8272567 1200W RF−LR
8272566 1800W RR
8272565 2500W LF
5
3191791 Spring, Locator
246119 Screw (8)
7
Switch, Infinite
3191049 1200W RR−LR
(Silver Shaft)
3191050 1800W RR
(Yellow Shaft)
4454541 2500W LF
(Red Shaft)
311865 Screw
8
3183956 Seal, Switch Cover
10
Knob, Control (4)
3196231 Black
3196232 White
14
3182435 Seal, Switch (4)
15
3191515 Bracket, Support
Element
16
Trim Ring, Cooktop
3193228 Black
3193227 White
3196537 Screw
17
3192452 Frame, Cooktop
21
3191952 Lamp, Indicator
3191953 Bumper, Rubber
9750835 Bumper, Door
