Planning Information
Warming Drawer
M O D E L W W D 3 0
Dimensions in parentheses are in
millimeters unless otherwise specified.
6
NOTE: Refer to the built-in 30" (762) single oven specifications for electrical location.
29
1
/
2
"
(749)
WARMING DRAWER
OPENING WIDTH
28
1
/
2
"
(724)
30-INCH OVEN
OPENING WIDTH
33"
(838)
CABINET WIDTH
E
5"
(127)
4"
(102)
OVERLAY APPLICATION
27
3
/
16
"
(691)
24"
min
(610)
24"
min (610)
OPENING DEPTH
24"
min (610)
CABINET DEPTH
1
1
/
2
"
min
*
(38)
10
1
/
4
"
(260)
OPENING
HEIGHT
9
7
/
8
"
(251)
2"
(51) x
2"
(51)
ANTI-TIP BLOCK
FLUSH INSET APPLICATION
27
3
/
16
"
(691)
24"
min
(610)
24"
(610) + THICKNESS
OF DRAWER FACE
FOR OPENING DEPTH
25"
min (635)
CABINET DEPTH
1
1
/
2
"
min
*
(38)
10
1
/
4
"
(260)
OPENING
HEIGHT
9
7
/
8
"
(251)
2"
(51) x
2"
(51)
ANTI-TIP BLOCK
*Dimension may increase depending on the size of the drawer front panel.
I N S T A L L A T I O N W I T H I N T E G R A T E D D R A W E R F R O N T
Model WWD30 with integrated drawer front installed with 30" (762) L Series or E Series single built-in oven.
D I M E N S I O N S
Minimum Cabinet Width
33" (838)
Minimum Cabinet Depth — Overlay
24" (610)
Minimum Cabinet Depth — Flush Inset
25" (635)
Rough Opening Width
29
1
/
2
" (749)
Rough Opening Height
10
1
/
4
" (260)
Rough Opening Depth (for flush inset, add thickness of drawer face)
24" (610)
See Installation Instructions shipped with drawer front for detailed specifications.
