EXPLODED VIEW & PARTS LIST
161 2M
-303672
O
pM
anual for
Countertop
Ele
ctr
ic Char
broilers
15
B44 Electric Charbroiler
Fig No
Part No
Qty
Description
1
H6-38623
1
GRATE MACH BROILER ASSY
2
H6-32740
1
COVER RR ELEM ASSY B44
3
WS-57507
1
CASTING ASSY ELEM REAR
4
2P-32428
1
SPRING SUPPORT ROD
5
2A-34061
1
ROD HEAD SUUORT B44/B446
6
H6-35593
1
PAN GREASE B44-50
7
2A-32840
1
PIVOT BRKT LF SIDE B40
8
2A-32841
1
PIVOT BRKT RT SIDE B40
9
2A-32806
2
COVER PIVOT BRKT
10
E7-37893
1
COVER ACCESS F101 ROHS
11
WS-57779
1
CONTACTOR 3POLE 208V 40A
WS-57780
1
CONTACTOR 3POLE 240V 40A
12
WS-50131
1
TERM BLK KIT 3-POLE 85AMP
13
DD-52128
1
TUBING TIMER WIRES F3672
14
2A-Z0314
4
FEET 4" DIE CAST.
2A-30586
4
FEET ADJ 4" GRAY PLASTIC
15
2J-30516
2
LIGHT SIGNAL AMBER M3938P
16 2R-30371
2 KNOB
ASSY
WARMERS
17
D8-30256
2
TRIM RING ASSY
18
2E-34593
2
SW INF 240V B CAM 13/16S
19
2M-300534
1
TRADEMARK DOMED LABEL
20
WS-500687
1
KIT HANDLE B44/446 B50/506
2R-300666
1
HANDLE BROILERS DIE CASTE
21
WS-57506
1
CASTING ASSY ELEM FRNT
22
WS-52737
1
ELEM ASSY 208V BASE B44, B50
WS-52738
ELEM ASSY 240V B44,50 BASE
23
WS-50020
18
ELEM 104V 300W BROILER
WS-50019
WLEM 115V 300W BROILER
NI 2E-35635
2 CAPCTR,
.015
