M10 Nylon Locknut (76)
M8 Nylon Locknut (65)
M6 Nylon Locknut (69)
M8 Flange Nut (19)
M8 Washer (59)
M10 Lock Washer (68)
M6 x 13mm Bolt (92)
M4 x 16mm Screw (62)
M4 x 19mm Screw (77)
M4 x 12mm Flat
Head Screw (85)
M10 x 25mm Button
Head Screw (87)
M8 x 19mm Button
Head Screw (86)
M10 Nut (47)
M4 x 5mm Screw (104)
M10 x 53mm Carriage Bolt (61)
M10 x 42mm Button Head Bolt (71)
1/4” x 12mm Flat
Head Screw (107)
M10 x 50mm Bolt (63)
1/4” x 45mm Screw (58)
1/4” x 16mm Screw (82)
M10 Washer (75)
1/4” x 25mm Screw (108)
PART IDENTIFICATION CHART
See the drawings below to identify small parts used in assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART LIST on the reverse side of this page.
Note: Some small
parts may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
If a part is missing, call toll-free 1-877-992-5999.
