Model 750t – White Outdoor Snow Boss 750T User Manual
Page 21
21
Model 750T
Ref.
No.
Part No.
Part Description
1.
712-0116
Lock Jam Nut 3/8-24
2.
756-0178
Flat Idler
3.
784-5632A
Auger Idler Arm
4.
710-0459A
Hex Cap Screw 3/8-24 x 1.50
5.
738-0281
Shoulder Screw
6.
736-0167
Flat Washer .656 ID x 1.25 OD
7.
732-0611
Extension Spring
8.
712-3068
Hex Nut 5/16-18
9.
710-0276
Carriage Bolt, 5/16-18 x 1.00
10.
736-0119
Lock Washer 5/16
11.
05931A
Housing
12.
741-0309
Ball Bearing
13.
710-0451
Carriage Bolt, 5/16-18 x .75
14.
705-5226
Chute Reinforcement
15.
684-0039C
24” Housing Assy
16.
712-3010
Hex Nut 5/16-18
17.
712-0429
Lock Nut 5/16-18
18.
736-0242
Belleville Washer
19.
736-0231
Flat Wshr, .344ID x 1.125 OD
20.
737-3000
Grease Fitting, 3/16” Drive
21.
731-1379B
Chute Adapter
22.
712-0324
Hex Lock Nut 1/4-20
23.
736-0463
Flat Washer
24.
784-0399
Bearing Housing w/Fitting
25.
710-0703
Carriage Screw 1/4-20 x .75
26.
710-0604
Hex Screw 5/16-18
27.
736-0169
Lock Washer 3/8
28.
712-0798
Hex Nut 3/8-16
29.
741-0245
Hex Flange Bearing
30.
784-5038B
Skid Shoe
31.
736-0242
Bell Washer
32.
712-3010
Hex Nut 5/16-18
33.
784-5581A
Shave Plate
34.
710-0451
Carriage Bolt 5/16-18 x 1.00
35.
684-0065
Impeller Assembly
36.
715-0114
Pin
37.
618-0414A
24” Gear Assy
38.
605-5188A
24” Spiral RH
39.
736-0188
Flat Washer
40.
741-0493A
Flange Bushing
41.
605-5189A
24” Spiral LH
42.
710-0890A
Shear Bolt 5/16-18 x 1.5
43.
784-5647
Chute Crank Bracket
44.
741-0475
Bushing
777D04524
Label: Side Housing
777D04535
Label: Engine
777D04587
Label: Top Housing SB 750T
777D04588
Label: Handle Panel
777I20324
Label: Transport
777I20820
Label: Panel LH
777I20821
Label: Panel RH
777S30511
Label: Chute Danger
777S30514
Label: Housing Danger
Ref.
No.
Part No.
Part Description
NOTE: For painted parts, please refer to the list
of color codes below. Please add the applicable
color code, wherever needed, to the part number
to order a replacement part. For instance, if a part,
numbered 700-xxxx, is painted Oyster Gray, the
part number to order would be 700-xxxx-0662.
Oyster Gray: 0662
Powder Black: 0637
Red Metallic: 0650
