This chart is provided to help you identify the small parts used in assembly. The number in parentheses below
each part refers to the key number of the part from the PART LIST on page 14 of this manual.

Important: Some

parts may have been pre-assembled for shipping purposes. If you cannot find a part in the parts bags,
check to see if it has been pre-assembled.

M10 Nylon Locknut (35)

12.5mm Spacer (33)

M8 Nylon Locknut (42)

M6 Washer (19)

M10 Washer (27)

M10 x 65mm Bolt (36)

M10 x 78mm Bolt (28)

M10 x 100mm Bolt (38)

M10 x 140mm Bolt (37)

M6 x 16mm Bolt (31)

M6 x 50mm Bolt (39)

M8 x 55mm Carriage Bolt (40)

M10 x 95mm Bolt (34)

M10 x 65mm Carriage Bolt (41)

PART IDENTIFICATION CHART
