Planning Information
48" (1219) Gas Rangetops
M O D E L S R T 4 8 8 , R T 4 8 6 C , R T 4 8 6 G , R T 4 8 4 C G , R T 4 8 4 D G A N D R T 4 8 4 F
Dimensions in parentheses are in
millimeters unless otherwise specified.
3
M O D E L O P T I O N S
Eight Burners RT488
Six Burners / Charbroiler RT486C
Six Burners / Griddle RT486G
Four Burners / Charbroiler
and Griddle
RT484CG
Four Burners / Double
Griddle
RT484DG
Four Burners / French Top RT484F
Natural gas models listed, for LP gas add
(-LP) to the model number.
V E N T I L A T I O N O P T I O N S
48" (1219) Pro wall or wall
chimney hood or liner
54" (1372) Pro wall, wall chimney
or island hood or liner
Also refer to the Pro Ventilation section of
our website, wolfappliance.com.
A C C E S S O R I E S
10 1 / 2 " (267) classic stainless steel
riser
Classic stainless steel island trim
Black control knobs
Porcelain-coated, cast iron wok
grate
Porcelain-coated, cast iron two-
burner S-grates
Hardwood cutting board—griddle
models only
High altitude conversion kit
Accessories are available through your
Wolf dealer. To obtain local dealer
information, visit the Showroom Locator
section of our website, wolfappliance.com.
S P E C I F I C A T I O N S
Overall Rangetop Width 48" (1219)
Overall Rangetop Height
(to cooking surface)
10 1 / 2 " (267)
Overall Rangetop Depth 27 1 / 4 " (692)
Surface Burners
16,000 Btu/hr (4.7 kW) burners with 500 Btu/hr
(.1 kW) delivered at simmer
Infrared Charbroiler 16,000 Btu/hr (4.7 kW)
Infrared Griddle 18,000 Btu/hr (5.3 kW)
Double Griddle (two burners) 18,000 Btu/hr (5.3 kW)
French Top 15,000 Btu/hr (4.4 kW)
Opening Width 48 1 / 4 " (1226)
Opening Height
(platform to countertop)
9 1 / 2 " (241)
Opening Depth 24" (610)
Electrical Supply Requirements 110/120 V AC, 50/60 Hz
15 amp circuit
Power Cord 6' (1.8 m) power cord
with grounded plug
Shipping Weight 220 lbs (100 kg) – 280 lbs (127 kg)
Specifications are subject to change without notice.
IMPORTANT NOTE: In non-island applications, a riser is required
when installing a gas rangetop against a combustible surface.
