Wright Manufacturing 98320008 - Manual (Page 14)

REF # PART NUMBER DESCRIPTION
1 SEE BELOW BLOWER ASSEMBLY
2 51410024 TAIL PIPE
4 98330002 BLOWER MOUNT
5 98320033 BOLT, FLANGE 3/8"-16 X 3/4 Z5
6 98320026 NUT, LOCK FLANGE 3/8"-16
9 98330003 GRASS COLLECTION RECEPTACLE FRAME
10 93460095 RECPTACLE FRAME SIDE SUPPORT, RIGHT
11 93460096 RECPTACLE FRAME SIDE SUPPORT, LEFT
12 98320023 BOLT, FLANGE 1//2"-13 X 1 1/4" Z5
13 12990022 NUT, LOCK FLANGE 1/2"-13 Z
14 98320046 THICK WASHER, 1/" ID
15 98320024 BOLT, FLANGE 5/16"-18 X 3/4" Z5
16 12990021 NUT, LOCK FLANGE 5/16"-18Z
17 SEE BELOW 2-Bag Catcher
18 SEE BELOW 3-Bag Catcher
19 98320052 OFFSET MOUNTING BRACKET -USED ON 52" TRIPLE ONLY
98320090 3.95" A-B PULLEY SHEAVE, 61" UNITS ONLY
98320089 4.5" A-B PULLEY SHEAVE, 52" UNITS ONLY
98320091 4.95"A-B PULLEY SHEAVE, 48" UNITS ONLY
21 93460091 TRANSFER HOSE GUARD, USED ON 48" ONLY
22 71460008 BUSHING, SPLIT TAPERED 1"
23 11990090 BOLT, HSC, 1/4"-20 X 1 PLAIN
24 98320047 MACHINE KEY 1/4" X 1/4" X 1"
98320087 BELT, 90" FOR 48" & 52" UNITS
98320092 BELT, 94" FOR 61" UNITS ONLY
27 98320013 GRASS COLLECTION COVER KIT, 48" & 52"
28 93460099 DECK STUD ADAPTER, 48" & 52" ONLY
29 98320014 GRASS COLLECTION COVER KIT, 61" ONLY
32 93460098 OPTIONAL 14.5 LB COUNTER - BALANCE WIEGHT
33 98320022 NUT, LOCKING 3/8"-24
REF #1
REF #17
REF #18
GRASS COLLECTION SYSTEM PARTS LIST
26
20
Refer to following sheets for detail parts illustrations.
Blower Assembly (Blower parts list / 18" Vertical Blower)
2-Bag Catcher (2-Bag Catcher parts list / 2-Bag Catcher)
3-Bag Catcher (3-Bag Catcher parts list / 3-Bag Catcher)
