75
6
2. Attach a Wheel (31) to the outside of the Base (1)
with an M10 x 108mm Bolt (81), three M10
Washers (75), and an M10 Nylon Locknut (76).
Do not overtighten the Locknut; the Wheel
must be able to turn easily.
Attach the other Wheel (not shown) in the
same manner.
2
1
31
75
76
75
81
3. Orient the Cross Tube (11) as shown, with the
welded tubes at the bottom. Attach the Foot Plate
(23) and the Cross Tube to the Upright (3) with
two M10 x 140mm Carriage Bolts (73), two M10
Washers (75), and two M10 Nuts (47).
Do not
insert a bolt into the upper hole in the Foot
Plate yet.
3
3
73
Welded
Tube
11
47
23
5. Lubricate an M10 x 103mm Bolt (66) with grease.
Attach the Bench Rail (5) to the Upright (3) with
the Bolt and an M10 Nylon Locknut (76).
Do not
overtighten the Locknut; the Bench Rail must
be able to pivot easily.
Tighten the Storage Knob (30) into the Upright (3)
and the Bench Rail (5).
4. Press the Front Leg Foot (27) onto the bottom of
the Front Leg (6).
Note that the front of the
Front Leg Foot is taller than the back.
Attach the Bench Rail (5), with the hook on the
bottom, to the Front Leg (6) with two M10 x
53mm Carriage Bolts (61) and two M10 Nylon
Locknuts (76).
4
5
5
Hook 76
76
27
Front
61
6
76
30
66
Lubricate
Insert the bolt
through this hole
5
3
