Bare Wall Installation

Even if you don’t have a studded wall phone plate, you can still
mount the TELETALKER on any wall surface within six feet of a
standard modular jack and AC outlet. To mount the phone farther
from the jack you’ll need a longer line cord or a telephone exten-
sion cord. In either case, place the AC power pack in a location
which will not be subject to disturbance.

Step 1: Measure and mark the wall for mounting screws.

Mark two points 3-

⁄

inches apart for upper and lower

mounting screws. The lower mark should be 48–52
inches from the floor. Use a level to make sure the
marks are aligned vertically.

Step 2: Install the mounting screws (not included).

Use wood screws for stud mounting, anchor screws for
hollow wall mounting. Drive the screws almost com-
pletely in, leaving a

⁄

inch space between the wall sur-

face and the bottom of the screw head (about the thick-
ness of two stacked pennies).

Step 3: Reverse the handset hanger to prevent the handset from

falling.

Step 4: Mount the TELETALKER.

Hang the telephone on the mounting screws and push
down gently until it snaps into place

Step 5: Connect the line cord to the jack on the top of the phone.

Plug the other end of the line cord into a modular wall
jack.

Make sure it snaps firmly into place.

Step 6: Connect the AC power pack to a wall AC outlet.

Step 7: Check for the dial tone.

If you can’t hear a dial tone, see In Case Of Difficulty,
page 12.

Note:

To disconnect the telephone, squeeze the clip on the
modular plug and pull it out of the jack.
