Wolf MULTI FUNCTION COOKTOP ICBIM15 - Manual (Page 10)

10
C O O K TO P F E A T U R E S
Integrated design allows for use with
multiple cooktop units and/or modules
Stainless steel top construction with classic
stainless steel finish
High-output 8.0 kW (581 g/h) dual-stacked
sealed burner
Automatic electronic reignition system
Individual spark ignition system
Equipped with gas safety shutoff valve
Illuminated control panel
Two interchangeable cast iron burner grates
with matte porcelain finish—wok grate and
low-profile continuous grate
Deep drawn burner pan
Electric rating: 220-240 V AC, 50/60 Hz,
1 amp
CE certified as a Class 3 appliance
Certified for the following category,
gas type and pressure:
I3P – G31 at 37 mbar
I2E – G20 at 20 mbar
I2E+ – G20/25 at 20/25 mbar
I2H – G20 at 20 mbar
W O L F M U LT I - F U N C T I O N C O O K TO P F E A T U R E S
Model ICBIM15/S
M O D E L I C B I M 1 5 / S
Gas Multi-Function Cooktop
V E N T I L AT I O N O P T I O N S
IMPORTANT NOTE: It is recommended that
you operate the Wolf multi-function cooktop
with either a Wolf cooktop ventilation hood,
downdraft system or Pro ventilation hood.
Contact your Wolf dealer for details.
Cooktop Wall Hood – 762 or 914 mm
widths in classic stainless steel.
Cooktop Island Hood – 1067 mm width in
classic stainless steel.
Pro Wall Hood – 559, 610 or 686 mm
depths and 762 to 1676 mm widths in
classic stainless steel.
Pro Wall Chimney Hood – 914 to 1372 mm
widths in classic stainless steel.
Pro Island Hood – 1067, 1372 and
1676 mm widths in classic stainless steel.
Pro Hood Liner – available in 873, 1178
and 1330 mm width hood shells.
All hoods have welded seams, sealed halogen
lighting and removable, dishwasher-safe filters.
Wok grate shown High-output 8.0 kW
(581 g/h) burner
Location of
rating plate Deep drawn pan
Illuminated
control panel
Continuous
control knob
