10
Rear View of the Product
Service port
AV-1
A. S-Video Input (black)
Connect to VCR or camcorder
B. Left (white) and right (red) audio inputs
Audio inputs are shared between the video and s-video inputs
C. Video Input (yellow)
Connect to a VCR or game consoles
AV-2
D. YPbPr Input (green, blue, red)
Connect to DVD players, DVD recorders or HDTV receiver
E. Left (white) and right (red) audio inputs
Connect to corresponding audio outputs for DVD or HDTV
TV
F. TV Input (silver)
Connect to antenna or cable service
AC IN (black)
G. 100-240VAC 50/60Hz, 1.5A Input
Connect to power
Service Port
Factory use only
