This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
each part refers to the key number of the part, from the PART LIST on page 14 of this manual. Important:
Some parts may have been pre-assembled for shipping purposes. If you cannot find a part in the parts
bags, check to see if it has been pre-assembled.
M10 x 60mm Bolt (27)
M6 x 16mm Screw (21)
M8 Washer (29)
M10 Nylon Locknut (30)
M8 x 65mm Bolt (22)
M8 x 50mm Bolt (35)
M8 x 55mm Bolt (34)
M8 x 40mm Carriage Bolt (26)
M6 x 38mm Screw (24)
M8 Nylon Locknut (23)
M6 Washer (25)
PART IDENTIFICATION CHART
