11
14. Attach the Seat (9) to the bracket on the Bench
Frame (5) with two 1/4” x 3/4” Screws (3).
15. Press a Frame Cap (7), into the Bench Frame (5).
Insert the Bench Pivot Rod (8) through the Bench
Frame (5) as shown. Center the Bench Pivot Rod
and slide a Bench Spacer (4) onto each end of it.
15
4
8
5
7
4
14
9
3
5
16. Press a 3/4” Inner Cap (12) into each end of the
Support Rod (25).
16
12
12
25
