CHASSIS PARTS
4
For Models: GR563LXSQ2, GR563LXSB2, GR563LXST2, GR563LXSS2
(White) (Black) (Biscuit) (Black Stainless)
W10187368
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 W10127969 Vent Tube Assbly
2
8273905 Support, Corner LR
3
Panel, Side (2)
8053830 White−Textured
8053832 Black−Textured
8272519 Biscuit−Textured
5
8522416 Seal, Oven Door
6
9757341 Element, Broil
7
9755770 Element, Bake
(Hidden Bake)
8
9757239 Rod − Door Switch
9
3196548 Fuse, Thermal
10
3195736 Support, Front (2)
11
3196037 Foot, Front (2)
13
8054068 Tray, Insulation
14
3196576 Clip, Panel (6)
15
9760314 Rail, Base (2)
16 W10058460 Foot, Rear (2)
17
3195987 Support, Corner RR
18
9761301 Screen − Catalyst
19
3186116 Support, Oven (2)
20
3186034 Bracket, Service
21
9761958 Block, Terminal
22
8274034 Back, Main
23
9757262 Switch, Door
24
3196701 Light Socket Assy
25
311255 Bulb, Oven Light
26
9755771 Cover, Tray
27
8273902 Sensor, Oven
28
3196165 Screw
29
3196179 Screw
30
3196178 Screw
31
3400016 Screw
33
3196172 Screw
34 W10031780 Screw
35
3196566 Screw
36
3196560 Screw
37
3196174 Screw
38
9758238 Retainer, Side (2)
39
9761490 Insulation
40
9761512 Clip − Mounting
41
9761013 Latch, Door
42 W10078380 Rod, Latch
43 W10107820 Latch Asy, Rear
44
9758701 Spacer, Door
45
3196169 Screw
46
9755769 Tray, Hidden
Bake Element
47
9759689 Card, Insulator
48
9758283 Cover, Box
49
112432 Nut (3)
50
9760407 Bracket−Mounting
INSULATION
8272616 Insulation, Wrap
9755772 Insulation, Back
8272613 Insulation, Vent
