APPENDIX: Wall mount and Base removal for the
42”/47”HD LCD TV

The TV has been fitted with two sets of VESA
mounting holes. The holes are spaced 75
mm and 100 mm equally apart for the 42”
product and 100 mm and 200 mm equally
apart for the 47” product. These mounting
location are provided strictly as an option to
the user for wall mounting.
It is the responsibility of the user to use a UL
Listed Wall Mount Unit rated to support the
weight of this TV. Please consult authorized
service personnel for the installation of this
Unit. Incomplete or inadequate mounting of
the unit to the wall may cause it to fall down, resulting in potentially serious injury.

Lay the LCDTV with front bezel down on a soft
and clear area. Please make sure that there is no
any foreign objects on the surface to avoid any
scratch or damage of the LCD panel

Remove the four screws as shown in Step -2

Remove the base from LCD TV as shown in
Step-3
