CONTROL PANEL PARTS
2
For Models: GY396LXPB00, GY396LXPQ00, GY396LXPT00, GY396LXPS00
(Black) (White) (Biscuit) (S.Steel)
8186214
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1
Control Panel
8191145 White
8191146 Biscuit
8191147 Black
8191148 S.Steel
3
9757476 Control, Migration
9780271 Screw
4
9757119 Bracket, Console
3179776 Screw (3)
5
3196068 Lens, Ind. (2)
6
9757410 Bracket, Control
486579 Screw
7
8523265 Housing, Ind. Lt.
8
Endcap
9756614BT Biscuit LH
9756614WH White LH
9756614BL Black LH
9756611BT Biscuit RH
9756611WH White RH
9756611BL Black RH
3196172 Screw
9
Knob
9756659BL Black
9756659WH White
9756659BT Biscuit
