Part identification chart – Weslo WLTL19012 User Manual
Page 17
Star Washer (33)–2
Handrail Bolt (12)–4
Wheel Bolt (14)–2
Frame Bolt (10)–2
Nut (42)–6
Handrail Washer (11)–4
Console Bolt (9)–2
Screw (5)–8
Formed Washer (31)–4
Remove this chart and use it to identify small parts during assembly. Save
this chart and the EXPLODED DRAWING/PART LIST for future reference.
PART IDENTIFICATION CHART
