2
PART # DESCRIPTION
MECHANICAL
51968 CLAMP, ELEM CTR SMALL GRIDDLE
51969 CLAMP, ELEM END SMALL GRIDDLE
51973 HANDLE, DOOR
53302 SEALANT 1/4x37 LONG
53474 CLIP, TIE-DOWN INSUL (pk 12)
53948 PANEL, FRONT GREASE DRAWER
55677 BRKT ELEM MTG RW
57407 INSUL FG (1” x 2ft x 4ft)
57748 FITTING, CONDUIT STRAIGHT 3/8
63738 BOOT, ROCKER SWITCH
63787 BRACKET, PROX.SWITCH
63797 WHEEL, BLOWER
63804 TRIM, LOWER FRONT
63817 GASKET, OVEN DOOR TOP&BTM
63918 GASKET, OVEN DOOR SIDES
63836 COVER, ELEM GASKET, INNER
63837 COVER, ELEM GASKET, OUTER
63889 CLIP, RACK SUPPORT (M4200)
63896 DOOR HINGE, BOTTOM ASSY
63899 PLATE, DOOR PIVOT
63900 SLEEVE, DOOR HINGE
63948 MAGNET, PERMANENT OVEN DOOR
65278 ASSEMBLY, GREASE TRAY
65644 KNOB, BLACK LLSC
65647 SHIELD, PROX. SWITCH
65653 KNOB, OVEN CONTROLLER
67439 KNOB OC-1 RS
68746 ADAPTER BAYONET 3/8-24x7/8
68989 GASKET, CLOSE CELL (rl 50ft)
PART # DESCRIPTION
MECHANICAL
500356 KNOB, BLACK (NOTE: GRAY OBS)
500984 SPACER, LATCH STRIKE PLATE
501389 REMOTE PULL STA ASSY
501451 BKT, SOLID ELEMENT HOLD-DOWN
501774 ASSEMBLY, GREASE DRAWER
502588 TUBING ASSY VACUUM UNIV HOOD
502772 GASKET SILICONE .25X.5X15.25
502773 GASKET SILICONE .25X.5X18.5
502782 FACEPLATE FRNT PNL UNIV HOOD
503252 GASKET, CLOSED CELL, OVEN POT
504112 LINK, FUSIBLE TYPE B 212ºF
504184 KIT, CONTROLLER SHIELD
504405 GREASE TRAY, HOOD DRIP
504444 ASSEMBLY, OVEN DOOR
504724 OVERLAY, CONTROL PANEL OC-1
505099 GLASS GLOBE VCS HOOD
505610 PIN, DOOR HINGE
505612 HANDLE, DOOR (M4200)
505615 ASSEMBLY, DOOR LATCH
505616 STRIKER, DOOR LATCH
505619 BUSHING, UPPER DOOR HINGE
PART # DESCRIPTION
OPTIONAL ACCESSORIES
20804 SET, CASTER, (2 FIXED, 2 SWIVEL)
21375 SUPPORT, OVEN RACK (M4200)
21376 RACK, OVEN (M4200)
22617 LEG, ADJ. (pk 2)
22618 PREFILTER
22619 FILTER PACK
22682 POWER CORD NEMA 15-60P 4’
22683 CAGE, PRE-FILTER
22684 GREASE BAFFLE (TYPE 3)
LITERATURE & DOCUMENTATION
302731 PLUMBING LAYOUT, VAC
302796 GLD VENTLESS SYS WOV-2HG
302874 ANSUL FIRE SUPPRESSION SYS
304350 INSTR INSTALL LEGS
304906 DIA WIRING WVOC-2HG 208/240V 3P
304963 OPMANUAL WVOC-2HG-SERIES
304982 SCHEMATIC WIRING WVOC
SV505 SERVICE MANUAL WVOC-2HG
PL505 S
e
rvi
c
e
Par
ts Li
st
for
W
V
OC-2
H Ventl
e
ss Coo
k
Center
