5
Model EFL33
www.waynepumps.com
1 Motor housing 28088-001 1
2 Power cord 31026-001 1
3 #8 - 16 x 1 inch screw 67112-001 6
4 Motor housing gasket 17456-002 1
5 Impeller 17317-001 1
6 Volute (includes 6 screws) 23272-001 1
7 Dielectric oil 55932 2.2 pints
8 Mechanical switch kit 60022-001 1
9 Oil plug 37303-001 1
Reference
Number Description Part Number Quantity
Repair Parts List
For replacement parts, call 1­800­237­0987
Please provide following information:
- Model number
- Serial number (if any)
- Part description and number as shown in parts list
Address parts correspondence to:
Wayne Water Systems
101 Production Drive
Harrison, OH 45030 U.S.A.
OIL
Tethered length to be
3 inches ± 0.25 inches
Figure 4
