Page 5

4) Select Energy Management Recovery OFF or ON –

Energy Management Recovery (EMR) causes the thermostat
to start heating or cooling early to make the building tem-
perature reach the program setpoint at the time you specify.
Heating will start 5 minutes early for every 1° of temperature
required to reach setpoint. Cooling allows more time per
degree because it takes longer to reach temperature.

Example: You select EMR and have your heating programmed
to 65° at night and 70° at 7 AM. If the building temperature
is 65° the difference between 65° and 70° is 5°. Allowing 5
minutes per degree the thermostat setpoint will change to
70° at 6:35 AM.

5) Select filter replacement run time - The thermostat will

display

“FLTR” after a set time of operation. This is a reminder

to change or clean your air filter. This time can be set from
0 to 1950 hours in 50 hour increments.

A selection of 000

will cancel this feature. When “FLTR” is displayed, you
can clear it by pressing HOLD and RUN at the same time.
This resets the timer and starts counting the hours until the
next filter change. Changing the time in the menu also resets
the timer.

6) Select Compressor Lockout LOC OFF or ON - Selecting

LOC ON will cause the thermostat to wait 5 minutes before
turning on the compressor if the heating and cooling system
loses power. It will also wait 5 minutes minimum between
cooling cycles. This is intended to help protect the compres-
sor from short cycling. Some newer compressors already
have a time delay built in and do not require this feature.
Your compressor manufacturer can tell you if the feature is
already present in their system. When the compressor time
delay occurs it will flash the (snowflake icon) for about five
minutes then turn on the compressor.

7) Select Temperature Display Adjustment 4 LO to 4 HI - Al-

lows you to adjust the room temperature display 4° higher or
lower. Your thermostat was accurately calibrated at the factory
but you have the option to change the display temperature
to match your previous thermostat.

8) Select F° or C° Readout - Changes the display readout to

Centigrade or Fahrenheit as required.

OPERATING FEATURES

Now that you are familiar with the thermostat buttons and display,
read the following information to learn about the many features
of the thermostat.

•

SIMULTANEOUS HEATING/COOLING PROGRAM STOR-
AGE — When programming, you can enter both your
heating and cooling programs at the same time. There is
no need to reprogram the thermostat at the beginning of
each season.

•

TEMPERATURE OVERRIDE — Press

until the

display shows the temperature you want. The thermostat
will override current programming and keep the room tem-
perature at the selected temperature until the next program
period begins. Then the thermostat will automatically revert
to the program.

•

HOLD TEMPERATURE — The thermostat can hold any
temperature within its range for an indefinite period without
reverting to the programmed temperature. Momentarily press
HOLD button.

“HOLD” will be displayed. Then choose the

desired temperature by pressing

. The thermostat

will hold the room temperature at the selected setting until
you press RUN button to start program operation again.

•

CONFIGURATION MENU — Allows you to customize
certain thermostat options.

PROGRAMMING YOUR THERMOSTAT

This section will help you plan your thermostat’s program to
meet your needs. For maximum comfort and efficiency, keep the
following guidelines in mind when planning your program.
• When heating (cooling) your building, program the
temperatures to be cooler (warmer) when the building is
vacant or during periods of low activity.
• During early morning hours, the need for cooling is
usually minimal.

Step

Press Button(s)

Displayed (Factory Default)

Press or to select:

COMMENTS

HOLD

(0:00)

0 to 8 hrs (in

15 minute increments)

(FA)

Select temporary Hold time

(ON)

OFF

LOC

(OFF)

0 HI

(0)

4 LO to

4 HI

(F)

Returns to normal operation

Select Energy Management Recovery OFF or ON

Select compressor lockout OFF or ON

Select temperature display adjustment higher or lower

Select temperature display to F or C

RUN

PRGM

and

RUN

HOLD*

d-L

(ON)

OFF

Select display backlight OFF or ON

HOLD*

Filter

(000)

0 to 1950 hours

(in 50 hour increments)

Select filter replacement run time

HOLD*

Select FA or SL (Fast or Slow) heating cycle rate

Configuration Menu

* Press

HOLD to advance to next item or TIME to move backwards to previous item

OPERATION
