Inst – White Rodgers 1F83-0471 User Manual

Page 5

INST

INSTALLER/CONFIGURA

ALLER/CONFIGURA

ALLER/CONFIGURATION MENU

TION MENU

1) This control can be configured for:

MS 2 – Multi-Stage System (no heat pump)
HP 1 – Heat Pump with one stage of compressor
HP 2 – Heat Pump with two stage compressor or two
compressor system, Gas or Electric backup
SS 1 – Single Stage System

2) GAS or Electric (ELE) fan operation. If the heating system

requires the thermostat to energize the fan, select ELE.
Select GAS if the heating system energizes the fan on a
call for heat.

3) Select Cool Sa

Select Cool Sa

Select Cool Savings™ v

vings™ v

vings™ value

alue

alue – Selects the amount of

adjustment for the Cool Savings™ feature in Cool mode
with 1 (1°) being the least amount of adjustment and 6 (6°)
being the most amount of adjustment. Default value is 3.
Cool Savings is an optional energy saving feature that can
reduce your cooling costs. It is based on the principal that
lower indoor humidity makes a slightly higher temperature
feel more comfortable. Cool Savings operates during
periods of high demand which normally occur onthe hottest
summer days when a cooling system may run for hours to
reach the thermostat setting. Long cooling run times also
lower the indoor humidity. Cool Savings, very slowly,
adjusts the setpoint temperature to make the setpoint closer
to the displayed room temperature, to a maximum of the
number of degrees you select. Adjusting the setpoint
temperature over a long cooling run time allows the system
to reach your set temperature and turn off. The room
temperature will actually be higher than the thermostat
displays but the reduction in humidity will allow comfort at
the slightly higher temperature.
To turn this feature on in the Cool mode press Cool

Cool

Cool Sa

Sav-

ings

ings. The display will show “Sa

“Sa

“Sav

ve”

e”

e” next to the setpoint

temperature. When Cool Savings is making adjustments to
the room temperature display “Sa

“Sa

“Sav

ve”

e”

e” will be flashing and

the displayed room temperature may vary within the adjust-
ment range you selected.
If "Sa

"Sa

"Sav

ve"

e" is not displayed and this feature is OFF, no

change will occur when the cooling system is continuously
running during periods of high demand.

4) Ener

Ener

Energ

gy Mana

y Mana

y Manag

gement R

ement R

ement Reco

eco

ecov

ver

ery

y: (this step is skipped if

configured to be non-programmable).
Energy Management Recovery (E) On enables the ther-
mostat to start heating or cooling early to make the building
temperature reach the program setpoint at the time you
specify. Heating will start 5 minutes early for every 1° of
temperature required to reach setpoint.
Example

Example

Example: E On is selected and your heating is pro-
grammed to 65° at night and 70° at 7 AM. If the building
temperature is 65°, the difference between 65° and 70° is
5°. Allowing 5 minutes per degree, the thermostat setpoint
will change to 70° at 6:35 AM. Cooling allows more time per
degree, because it takes longer to reach set temperature.

5, 6 & 7) Cycle Rate Selection

Cycle Rate Selection

Cycle Rate Selection – The factory default setting for

Heat and Cool modes, SS1, MS2, is medium cycle (ME).
For Heat Pump, HP1, HP2, the default setting is medium
(ME). For Emer (Aux) the default setting is fast cycle
(FA).To change cycle rate, press the

key.

Cycle rate differentials for different settings are:

MODE

Fast

Medium

Slow

Heat (SS1, MS2)

0.4°F

0.6°F

1.7°F

Cool (SS1, MS2)

0.9°F

1.2°F

1.7°F

Heat Pump (HP1, HP2)

0.9°F

1.2°F

1.7°F

Emer (HP1, HP2)

0.6°F

1.7°F

8) Select Compr

Select Compr

Select Compressor Loc

essor Loc

essor Lock

kout CL OFF or ON

out CL OFF or ON

out CL OFF or ON – Selecting

CL ON will cause the thermostat to wait 5 minutes between
cooling cycles. This is intended to help protect the compres-
sor from short cycling. Some newer compressors already
have a time delay built in and do not require this feature.
Your compressor manufacturer can tell you if the lockout
feature is already present in their system. When the
thermostat compressor time delay occurs, it will flash the

setpoint for up to five minutes.

9) System Mode Configur

System Mode Configur

System Mode Configura

ation

tion

tion – This thermostat is config-

ured for Heat and Cool (SYSTEM switch with Cool Off
Heat) default. It can also be configured for Heat and Cool
with Auto changeover (Heat, Auto, Cool, Off), Heat only
with fan (Off Heat), Heat only without fan, Auto only
(Auto Off), and Cool only (Cool Off).

10) Select Bac

Select Bac

Select Backlight Displa

klight Displa

klight Display

y – The display backlight improves

display contrast in low lighting conditions. When the "C"
terminal is powered, selecting backlight CdL ON will keep
the light on continuously. Select backlight OFF will turn the
light on momentarily after any key is pressed. When the
"C" terminal is not powered, the light will be on momen-
tarily after any key is pressed no matter whether the
backlight is selected ON or OFF.

11) Select

Select

Select T

Temper

emper

empera

atur

tur

ture Displa

e Displa

e Display

y Adjustment 4 L

Adjustment 4 L

Adjustment 4 LO to 4 HI

O to 4 HI

O to 4 HI –

Allows you to adjust the room temperature display up to 4°
higher or lower. Your thermostat was accurately calibrated
at the factory, but you have the option to change the dis-
play temperature to match your previous thermostat. The
current or adjusted room temperature will be displayed.

12) Select F° or C° R

Select F° or C° R

Select F° or C° Readout

eadout

eadout – Changes the display readout

to Centigrade or Fahrenheit as required.

13) Pr

Pro

grrrrram Options

am Options

am Options: 1F85 only, configured for 5/1/1 day or

5/2 day programming or non-programming mode.
The default setting is P2, indicating 5/2 day programming.
The programs per week can be toggled to P3 or P0 by
pressing the

keys. A selection of 0 Days for

non-programmable will eliminate the need for EMR, and
that step in the menu will be skipped.

14 & 15) Select

Select

Select A

Automa

utoma

utomatic Sc

tic Sc

tic Schedule

hedule

hedule – 1F85 only, with just

one touch of the A

Auto Sc

uto Sc

uto Schedule

hedule

hedule key this feature allows

you to program a desired comfort temperature into all the
program periods along with a 6° set back for night periods
of both Heat and Cool programs. Factory default is "On" for
both. When Hea

Hea

Heat

t AS On

AS On

AS On and Cool

Cool

Cool AS On

AS On

AS On are activated

while in Heat or Cool mode, select desired setpoint tem-
perature and press A

Auto Sc

uto Sc

uto Schedule

hedule

hedule. This value will be

copied into all the morning, day and evening program
periods. The night program periods will have a 6°F set back.

16 & 17) Select F

Select F

Select Fast Second Sta

ast Second Sta

ast Second Stag

ge ON or OFF

e ON or OFF

e ON or OFF – Heat pump

or Multi-stage only, in the run mode, with the fast Heat
feature enabled (FA Heat On), if the Heat setpoint tem-
perature is manually raised by 3°F (2°C) or more above
the actual temperature using

the second stage will

energize immediately. With FA OFF, second stage will not
energize until the setpoint temperature is 1°F or more
above actual temperature for more than ten minutes. The
Fast Cool feature (FA Cool) provides the same controls
when the setpoint temperature is lowered.

18) Select Da

Select Da

Select Daylight Sa

ylight Sa

ylight Saving

ving

ving Time Calcula

Time Calcula

Time Calculation

tion

tion – 1F85 only,

this feature will allow the thermostat to calculate the DST
automatically and apply it to the Real Time Clock display.
Default On. Use

touch keys to select the

feature OFF.

19) Select Filter R

Select Filter R

Select Filter Re

eplacement

placement

placement R

Reminder and Set

eminder and Set

eminder and Set R

Run

un Time

Time

Select the "Chang

Chang

Change Filter

e Filter

e Filter" reminder On or OFF. If selec-

ted On, press MENU

MENU to select the time period from 25 to

1975 hours in 25 hours increments. In a typical system,
200 hours (default) of run time is approximately 30 days.
After the selected time of blower operation, the thermostat
will display "Chang

Chang

Change Filter

e Filter

e Filter" as a reminder to change or

clean your air filter. When "Chang

Chang

Change Filter

e Filter

e Filter" is displayed,

press MENU

MENU or R

RUN SCHED

UN SCHED

UN SCHED button to clear the

display and restart the time to the next filter change.

20) Select R

Select R

Select Re

ver

ersing

sing

sing V

Valv

alv

alve Output

e Output

e Output – The O/B option is

factory set at "O" position. This will accommodate the
majority of heat pump applications, which require the
changeover relay to be energized in COOL. If the thermo-
stat you are replacing or the heat pump being installed with
this thermostat requires a "B" terminal, to energize the
changeover relay in HEAT, the O/B option should be set at
"B" position.
