PARTS
OM 0352SB-A
24
S
NOWBLOWER
A
SSEMBLY
R
EF
. D
ESCRIPTION
Q
TY
. P
ART
#
1
Snowblower housing and foot rest
1
667619
2
1 stage auger
1
667620
3 Cutting
edge
1
667643
4 Skid
shoes
2
667626
5 Chain
guard
1
667629
6 Driveline
shield
1
667630
7 Gearbox
shield
1
667631
8 Pedal
stopper
1
667632
9
Bearing flange 3 holes with nut
2
665743
10
Chain 3/16"
2
667652
11 Spacer
ring
1
667666
12
Chain tensioner automatic
1
665960
13 Torsion
spring
1
2200012
14
Tension spring 1/2" x 3 9/16"
1
659578
15
Tension spring 1 1/2" x 9"
2
657363
16
Chain #40 74 links (with connecting link)
1
3300018
17
Connecting link #40
1
659721
18
1" Bearing with allen socket set screw
2
665494
19
Grease fitting 1/4" NF
5
654106
20
Clevis 1/4" body, 5/16" pin
4
A-10368
21
Circle cutter ø1" X 1/16"
4
1900009
22
Pin ø1/2" x 2 1/4" PTD
1
4600036
23
Cotter pin Ø1/8" X 1 1/2"
1
1500018
24
Hex. bolt ø1/4"NC X 1/2" GR.5 ,PTD
2
0100001
25
Hex. bolt ø1/4" NC X 5/8" Gr.5 PTD
2
0100002
26
Hex. bolt Ø1/4" X 2 3/4" NC GR.5 PTD
1
0100013
27
Carriage bolt 5/16" NC X 3/4" PTD
10
0300002
28
Serrated flange bolt 5/16"NC X 1/2" PTD
8
0200065
29
Hex. bolt 5/16" NC X 1" LG. GR.5, PTD
2
0100019
30
Hex. bolt 5/16" NC X 1 1/4" LG. GR.5, PTD
2
0100020
31
Serrated flange nut 1/4" NC. PTD
5
0900058
32
Serrated flange nut 5/16" NC, PTD
12
0900036
33
Nylon insert locknut 5/16" NC, GR.5, PTD
2
1000005
34
Flat rectangular grip 1 1/4" X 1/4"
1
663997
35
Lift bracket #5628-2
2
4200018
