Wells COUNTERTOP WARMERS SW-10T - Manual (Page 4)

FEATURES & OPERATING CONTROLS
2
A. THERMOSTAT
1. On THERMOSTATICALLY CONTROLLED warmers, power is
applied to the heating element according to the control knob
position and the actual temperature at the temperature sensing
thermobulb.
2. The desired temperature is controlled by rotating the
TEMPERATURE CONTROL KNOB. The knob has a numeric
scale, where higher numbers correspond to higher temperature.
3. On warmers equipped with an INDICATOR LIGHT, the light will
glow when the thermostat is calling for heat (i.e. the element is
energized).
4. The TEMPERATURE CONTROL KNOB will rotate
approximately 300º, and will reach a “stop” at both ends.
The OFF position is marked.
NOTE: The dial position is an indication of the temperature
setting. Actual temperature will vary depending upon the type of
product and food consistency.
B. ADJUSTABLE
LEGS
1. Countertop warmers are equipped with adjustable legs.
These legs allow for:
a. leveling the warmer
b. ventilation around the warmer, and
c. cleaning under the warmer.
2. Adjustable legs are supplied with the warmer, the legs
MUST be properly installed before the warmer is placed
into operation.
MOUNT INTO
THREADED
HOLES IN
WARMER
FRAME
TURN BOTTOM
PORTION TO
ADJUST
