Part identification chart – Weslo WLTL25320 User Manual

Page 17

background image

Star Washer (29)–2

3/4” Tek Screw

(3)–4

Wheel Bolt (67)–2

Frame Bolt (70)–2

3/8” Nut (61)–6

Handrail Bolt (42)–4

3/4” Screw (2)–12

Upright Bolt (65)–4

1/4” Washer

(38)–4

3/8” Washer

(66)–8

Spacer Screw

(89)–2

Remove this chart and use it to identify small parts during assembly. Save
this chart and the EXPLODED DRAWING/PART LIST for future reference.

PART IDENTIFICATION CHART
